Lightweight Uncooled Thermal Imaging Module 120×90/12μm for AIoT Applications with USB 2.0 Interface
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Storage Temperature | -45℃~+85℃ | Thermal Imaging Sensor | 120x90/12µm |
|---|---|---|---|
| Temperature Measurement Accuracy | Greater Of ±2℃ / ±2% | Output Data | 14bit Raw |
| Spectral Response | 8~14μm | NETD | ≤50mK |
| Highlight | Lightweight Uncooled Thermal Imaging Module,Uncooled Thermal Imaging Module For AIoT |
||
Product Description
Lightweight Uncooled Thermal Imaging Module 120×90/12μm for AIoT Application
The iMC112 infrared miniature module is built on our self-developed TIMO112 platform, specifically designed for mobile terminal applications. Paired with a dedicated application, it outputs images and temperature matrices directly without requiring temperature calibration, streamlining the development process. This ultra-compact module offers exceptional cost-effectiveness and low power consumption, featuring universal control interfaces that simplify integration and reduce technical barriers to infrared thermal imaging technology.
The iMC112 infrared miniature module finds applications across multiple industries including AIoT, Machine Vision, Industrial Vision, and Security Monitoring.
Main Features
Portable and Cost-Effective
- Equipped with self-developed 120×90/12μm wafer-level infrared detector for significant cost advantages
- Ultra-compact design optimized for mobile and portable devices
Robust Structure, Reliable Performance
- Dedicated application outputs thermal images and temperature matrices with universal compatibility
- Encased in structural components for enhanced reliability and system completeness
Mainstream Interfaces, Easy Development
- Standard USB 2.0 digital video output interface for broad compatibility
- Factory-calibrated temperature data eliminates additional development requirements
Technical Specifications
| Model | iMC112 |
|---|---|
| Resolution | 120×90 |
| Pixel Size | 12μm |
| Spectral Response | 8~14μm |
| NETD | ≤50mK |
| Output Data | 14bit Raw |
| Frame Rate | 25Hz |
| Focus Mode | Focus Free |
| Lens (HFOV/FL) | 50°/1.6mm |
| Digital Video Interface | USB2.0 |
| Operating Voltage | 3.3V±0.1V |
| Typical Power Consumption | 150mW |
| Temperature Measurement Range | -20℃~+550℃(-20℃~+150℃ | +100℃~550℃) |
| Temperature Measurement Accuracy | Greater of ±2℃ / ±2% |
| Operating Temperature | -20℃～-60℃ |
| Humidity | 5%~85% |
| Storage Temperature | -45℃~+85℃ |
| Certification | CE, FCC, RoHS |
Frequently Asked Questions
What are the Key Advantages of Plug-in Thermal Cameras?
Portability: Compact, lightweight design compatible with smartphones, tablets, and drones—eliminating the need for bulky standalone equipment.
Cost-Effectiveness: Priced significantly lower than professional thermal cameras, making thermal imaging accessible to small businesses, consumers, and budget-conscious industries.
Versatility: Adaptable to multiple applications through interchangeable attachments including smartphone cases, drone payloads, and industrial adapters.
Ease of Use: Intuitive applications provide data visualization, temperature measurement, and image sharing capabilities—no specialized training required for basic operation.
Cost-Effectiveness: Priced significantly lower than professional thermal cameras, making thermal imaging accessible to small businesses, consumers, and budget-conscious industries.
Versatility: Adaptable to multiple applications through interchangeable attachments including smartphone cases, drone payloads, and industrial adapters.
Ease of Use: Intuitive applications provide data visualization, temperature measurement, and image sharing capabilities—no specialized training required for basic operation.
About SensorMicro
SensorMicro is a global leader in infrared detector manufacturing and service provision. We provide high-performance uncooled and cooled thermal imaging detectors to customers worldwide while sharing our extensive professional application expertise.
We deliver advanced infrared detectors, camera cores, and modules with versatile formats and wavebands. Our products are engineered for exceptional clarity, sensitivity, and efficiency, seamlessly integrating into diverse systems to empower next-generation imaging and sensing applications across industries.
SensorMicro detectors are widely utilized in thermography, security & surveillance, personal vision, automotive systems, and consumer infrared products. Our volume production capabilities ensure we can meet growing demand across all existing and emerging markets.
