2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision

I'm Online Chat Now

2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision

2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision
2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision

Large Image :  2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision

Product Details:
Place of Origin: WUHAN
Brand Name: GST
Model Number: IR516C
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Payment Terms: L/C, T/T
Detailed Product Description
Type: Uncooled Thermal Binocular Thermal Imaging Sensor: 640x512/12µm
Dimension: ≤215x170x100mm Weight: ≤1.5KG
High Light:

4x Magnification Thermal Imaging Binoculars

,

Night Vision Uncooled Thermal Imaging Binoculars

Lightweight 640x512 Uncooled Thermal Imaging Binoculars For Night Vision

Thermal Binocular


Light Weight 640x512 Uncooled Thermal Imaging Binoculars for Night Vision


Product Description


The IR516C portable uncoooled thermal binocular integrates the 640x512 uncooled VOx FPA microbolometer with spectral range of 8~14μm and ensures very stable performance. Its binocular design reduces eye fatigue during longer viewing and enhances the natural look of objects.

Combined with the 640x512/12µm highly-sensitive thermal imaging sensor, this thermal imaging binocular provides exceptional detection capabilities. The smallest temperature differences will be clearly visible and hidden targets can be detected in very poor light conditions or total darkness, especially in harsh weather with wind, fog, rain and snow.

Global Sensor Technology is a supplier of cooled uncooled infrared detectors and infrared thermal imaging modules. We have more than 10 years of experience about infrared thermal imaging applications and a set of mature solutions available for customers. At the same time, we also have professional after-sales service team to provide you with professional reply. For any questions or problems, please contact us at any time, we will be in the first time for you to answer.



Main Features


- Realize detection, identification and recognition of targets with thermal imaging technology
- Built-in photo, video recorder and replay functions
- Output photo and video via USB interface
- Support infrared electric focusing, pseudo color, 2х/4x magnification and cursor control
- Support adjustment of infrared contrast, brightness, auto compensation and display control of heat trace


Specifications



Model IR516C
Infrared Camera
Detector Uncooled VOx FPA Microbolometer
Resolution 640x512
Pixel Pitch 12μm
Spectral Range 8-14μm
Infrared Optics
Focal Length 61mm
FOV 7.32°X5.86°
F# 0.8
Storage
Memory 32G
Pic Format JPG
Video Format AVI
Display
Color OLED High Resolution OLED
Ocular Monocular
Power Supply
Input Voltage DC12V±0.5V
Battery 18650/2 pcs
Continuous Working Time >4hs (Room Temp.)
Physical Characteristics
Weight ≤1.5kg
Dimension ≤215x170x100mm
Mount Type 1/4" Socket
Environmental Adaptability
Working Temperature -40 ℃-+55℃
Storage Temperature -40℃-+60℃
Accessories
Standard Battery
Charger
Portable Bag
Safety Box
External Cable
External Display Terminal
Power Adaptor
Tripod
Portable Bag



FAQs



1.Thermal imaging binoculars vs. night vision binoculars



Compared with thermal imaging binoculars, night vision binoculars are much cheaper.



Thermal imaging binoculars collect infrared radiation and turn it into a thermogram. They don’t rely on light and nor emit infrared ray actively. They can be effective in day and night which has poor light conditions or total darkness and even in harsh environments such as rain, snow, dust and haze etc.



While night vision relies on visible light. They collect ambient light, moonlight or starlight and amplify it to detect targets in the dark. They cannot be used during the day, because they maybe damaged. And also they cannot see through bushes, smoke, fog or rain.



About Global Sensor Technology


2х/4x Magnification Uncooled Thermal Imaging Binoculars For Night Vision 0
Global Sensor Technology is the world leading infrared detector manufacturer and service provider. It is willing to provide customers all over the world with high performance uncooled and cooled thermal imaging detectors and share its professional application experience.

Global Sensor Technology is located at Optics Valley, China. The company covers an area of 30 thousand square meters with 20 thousand square meters clean room settled for its three 8 inch fabrication lines. GST IR detectors have been widely used in thermography, security & surveillance, personal vision, automotive and consumer infrared products. The volume production capability of GST enables it to meet the growing demand from all existing and emerging markets.
