High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search

I'm Online Chat Now

High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search

High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search
High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search

Large Image :  High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search

Product Details:
Place of Origin: WUHAN
Brand Name: GST
Model Number: IR522-WM
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Payment Terms: L/C, T/T
Detailed Product Description
Type: Uncooled Thermal Binocular Infrared Detector: 640×512/12μm
LRF Range: Min Range≤50m; Max Range: ≥6km Storage Temperature: -55 °C ~+70°C
High Light:

High Accuracy Uncooled Thermal Imaging Binoculars

,

Search Uncooled Thermal Imaging Binoculars

,

12um Handheld Infrared Vision Binoculars

Handheld Uncooled Thermal Imaging Binoculars For Search And Surveillance

Brief Introduction



IR522-WM Handheld Uncooled Thermal Binocular



Product Description



The IR522-WM is a kind of handheld uncooled thermal binocular that could work at night or bad weather condition for search and surveillance purpose.


It integrates infrared camera, visual camera, laser rangefinder, positioning, digital compass and memory module. Users could carry out long range missions, like scout, target range finding, target positioning, etc.



Main Features



- With high accuracy, repeat frequency, stable laser rangefinder
- Support self and target positioning function that has fast operation, strong signal and high accuracy
- With target recognition and mark functions



Specifications



Model IR522-WM
Infrared Camera
Detector Type Uncooled VOx FPA Microbolometer
Resolution 640×512
Pixel Pitch 12μm
FOV ≥6.1°×5.0°
Visual Camera
Field of View ≥3°x2.2°
Fog Penetration Yes. When visibility ≤4km, fog penetration ratio ≥1.5
Laser Rangefinder
LRF Range Min Range≤50m; Max Range: ≥6km
Measuring Error ≤2m
Accuracy Rate ≥98%
Laser Wavelength 1.535μm, Safe band for human eyes
Interface (With external power supply interface)
Data Interface Standard USB Port
Video Interface Standard PAL
Communication Interface Standard RS232
Beidou Positioning Accuracy
Horizontal Positioning ≤10m (CEP)
Elevation Positioning ≤10m (PE)
Positioning Accuracy
Magnetic Azimuth Accuracy ≤0.5° (RMS, Inclination Range -15°~+15°)
Target Positioning Accuracy ≤20m (CEP) When the observation distance is 2km
Power Supply
Continuous Working Time ≥10h (Room Temperature)
Physical Characteristics
Net Weight ≤1.6kg
Gross Weight ≤2.3kg
Environmental Adaptability
Working Temperature -40 °C ~+55°C
Storage Temperature -55 °C ~+70°C



FAQs



1.Thermal imaging binoculars vs. night vision binoculars



Compared with thermal imaging binoculars, night vision binoculars are much cheaper.



Thermal imaging binoculars collect infrared radiation and turn it into a thermogram. They don’t rely on light and nor emit infrared ray actively. They can be effective in day and night which has poor light conditions or total darkness and even in harsh environments such as rain, snow, dust and haze etc.



While night vision relies on visible light. They collect ambient light, moonlight or starlight and amplify it to detect targets in the dark. They cannot be used during the day, because they maybe damaged. And also they cannot see through bushes, smoke, fog or rain.



About Global Sensor Technology



High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search 0

High Accuracy Uncooled Thermal Imaging Binoculars Handheld For Search 1



Global Sensor Technology is the world leading infrared detector manufacturer and service provider. It is willing to provide customers all over the world with high performance uncooled and cooled thermal imaging detectors and share its professional application experience.

GST IR detectors have been widely used in thermography, security & surveillance, personal vision, automotive and consumer infrared products. The volume production capability of GST enables it to meet the growing demand from all existing and emerging markets.
