25fps Visible Light And Low Light Handheld Laser Rangefinder

Place of Origin WUHAN
Brand Name GST
Model Number IR5212-WM
Minimum Order Quantity 1 Piece
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Type Handheld Laser Rangefinder Low Light Resolution 1920Hx1200V
Visible Light Resolution 2560Hx1440V Power Consumption 3.5V
High Light

Visible Light Handheld Laser Rangefinder


Low Light Handheld Laser Rangefinder


25fps Portable Laser Rangefinder

Leave a Message
Product Description
Brief Introduction


IR5212-WM New Handheld Laser Rangefinder


Product Description


The IR5212-WM is a new hand-held laser rangefinder with a certain ability to identify camouflage. The product has two modes: visible light and low light, which can be used for day and night observation.


Main Features


- Two modes switch freely: visible light / low light
- Various control functions: image / video storage, playback and delete
- Support undervoltage indication, battery reverse connection protection
- Support speech recognition and broadcast
- Support measuring distance between multiple target points
- Support to memorize target bearing, distance, and time
- Support power control (on/off), switching mode, contrast adjustment, brightness adjustment, focusing
- Support video output, serial communication interface, local OLED display and connection to external display




Model IR5212-WM
Low Light
Detector 12μm Low Illuminance Digital CMOS Image Sensor
Resolution 1920Hx1200V
Frame Rate 25fps
Focus Length 70mm
FOV 9°x6.7° (±5%)
Visible Light
Detector 3μm Digital CMOS Image Sensor
Resolution 2560Hx1440V
Frame Rate 25fps
Focus Length 105mm
FOV 3°x2.2° (±5%)
Memory 64GB
Pic Format JPEG/PNG
Video Format AVI
Color OLED High Resolution Color OLED
Ocular Monocular
Video PAL
Digital USB
Power Supply
Built-in Battery 18650
Power Consumption 3.5V
Environmental Adaptability
Working Temperature -40℃~+55℃
Storage Temperature -55℃~+70℃
Physical Characteristics
Weight ≤1.6kg
Dimension ≤221mmx105mmx141mm
Standard Battery
Safety Box
External Cable
Power Adapter
Optional Tripod
Portable Bag


About Global Sensor Technology


25fps Visible Light And Low Light Handheld Laser Rangefinder 0

Global Sensor Technology is the world leading infrared detector manufacturer and service provider. It is willing to provide customers all over the world with high performance uncooled and cooled thermal imaging detectors and share its professional application experience.

Global Sensor Technology is located at Optics Valley, China. The company covers an area of 30 thousand square meters with 20 thousand square meters clean room settled for its three 8 inch fabrication lines. Thanks to the innovative and experienced staff, advanced fabrication facilities, and cutting-edge technique level, all key fabrication processes such as element purification, epitaxy growth, chip tape-out and fabrication, vacuum packaging can be done in house. The company successfully launched state-of-the-art VOx uncooled detectors, MCT and T2SL cooled detectors with full intellectual property. The product portfolio covers many different array formats, various pixel size and multiple spectral band combination, all products with high thermal sensitivity and reliability.

GST IR detectors have been widely used in thermography, security & surveillance, personal vision, automotive and consumer infrared products. The volume production capability of GST enables it to meet the growing demand from all existing and emerging markets.
