10KM Airborne 2 Axis Multi Sensors EO IR Systems For Small UAV

I'm Online Chat Now

10KM Airborne 2 Axis Multi Sensors EO IR Systems For Small UAV

10KM Airborne 2 Axis Multi Sensors EO IR Systems For Small UAV
10KM Airborne 2 Axis Multi Sensors EO IR Systems For Small UAV

Large Image :  10KM Airborne 2 Axis Multi Sensors EO IR Systems For Small UAV

Product Details:
Place of Origin: WUHAN
Brand Name: GST
Model Number: GDES-210D10
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Payment Terms: L/C, T/T
Detailed Product Description
Name: EO IR Systems Maximum Range: 10KM
High Light:

Small UAV EO IR Systems

,

10KM EO IR Systems

,

Airborne 2 Axis Electro Optics Systems

Brief Introduction



GDES-210D10 Airborne 2-Axis Multi Sensors Observation Pod



Product Description



The GDES-210D10 airborne 2-axis multi sensors observation pod adopts a spherical stable platform with a diameter of 230mm. It is equipped with a 1080P low-illuminance visual camera, a cooled infrared camera and a laser rangefinder.


The pod weighs less than 10KG and is suitable for small UAVs to search, observe targets. It has the functions of target positioning and geographic guidance based on the aircraft information.



Main Features



- High stability accuracy up to 0.04mrad
- Core infrared detector with self-developed intellectual property right
- Support real-time output of thermal image and visible image
- With inertial image stabilization, locking, scanning functions
- With airborne information for target positioning



Specifications



Model GDES-210D10
Infrared Camera
Detector Type Cooled MWIR Focal Plane Array
Resolution 640x512
Pixel Pitch 15μm
Horizontal FOV 2.5°×2° ~ 18.18°×14.58°
Focal Length 30~220mm Continuous Zoom
Visual Camera
Resolution 1920×1080
Focal Length 10~150mm Continuous Zoom
FOV 2.27°×1.27° ~ 33.14°×19.00°
Laser
Wavelength 1.54μm (Safe for Human Eyes)
Maximum Range ≥10KM
LRF Accuracy ±2m
Servo System
Motion Range 360° Continuous Azimuth; -120 ~+10° Elevation
Stabilization Accuracy ≤ 0.04mrad (RMS)
Angle Measurement Accuracy ≤1mrad
Maximum Angular Velocity ≥60°/s
Electrical Interface
Working Voltage DC28V (Support 18~36V Input)
Power Consumption ≤100W (Average)
Video Interface Ethernet
Physical Characteristics
Weight ≤10KG
Dimension ≤200mm×300mm (OD×H)
