Uncooled FPA Thermal Imaging Detector 400x300 / 12μM Used In UAV Payloads

Place of Origin Wuhan, Hubei Province, China
Brand Name GST
Certification ISO9001:2015; RoHS; Reach
Model Number GST412M
Minimum Order Quantity 100 Pieces
Price Negotiable
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Resolution 400x300 / 12μm NETD <30mK
Spectral Range 8~14μm Size 30x19.8x7.32mm
High Light

UAV Payloads Thermal Imaging Detector


Uncooled Thermal Imaging Detector


High Sensitivity Uncooled Infrared Detectors

Leave a Message
Product Description
GST412M Uncooled Infrared Detector


400x300 / 12μm Uncooled FPA Thermal Imaging Detector Widely Used in UAV Payloads


Product Description


GST412M uncooled infrared focal plane detector is developed by Global Sensor Technology (GST). With standard 400x300 QVGA format at 12μm, the GST412M vanadium oxide microbolometer will exceed your most demanding requirements.


GST412M metal package infrared detector integrates the mainstream vanadium oxide (VOx) microbolometer on the market, the built-in TEC technology readout circuit that keeps stable performance and vacuum package that avoid heat exchange.


GST412M VOx thermal sensor has characteristics of high sensitivity, stable performance and can present clear imaging quality in various kinds of harsh working environment such as total darkness, thick fog, heavy rain, snow, sand storm etc.


Main Features


- NETD<30mk, High Sensitivity

- Mature Technology

- Stable Performance

- Long Operating Life

- Clear Image Quality & Details

- Strong Environmental Adaptability


Product Specifications


Model GST412M
Material VOx
Resolution 400x300
Pixel Pitch 12μm
Spectral Range 8~14μm
NETD <30mK
Digital Output Built-in 14bits ADC
Typical Responsivity 15mV/K
Thermal Response Time <12ms
Frame Rate 50/60Hz
Power Consumption <200mW
Dimension (mm) 30x19.8x7.32
Weight <18g
Operation Temperature -40°C ~ +85°C


Industrial Applications


The GST412M thermal imaging detector is widely used in many areas, such as Thermography, Security & Monitoring, Outdoors, Law Enforcement & Rescue, ADAS, UAV Payloads etc.


Uncooled FPA Thermal Imaging Detector 400x300 / 12μM Used In UAV Payloads 0



Hornors & Certificates


Uncooled FPA Thermal Imaging Detector 400x300 / 12μM Used In UAV Payloads 1




1. What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. It converts invisible infrared radiation into visible infrared thermal image with temperature distribution of the target surface. Different objects and even different parts of the same object have different radiation ability and infrared reflection strength.


2. What can infrared imaging be used for?

-Night vision

-Search & rescue

-Non-destructive test

-Epidemic prevention


-Security & monitoring



3. What is thermal imaging module?

A thermal imaging module usually consists of an infrared detector, infrared lens and hardware electronics with software and algorithm embedded. It is the minimum unit of a thermal imaging device.
