10mK NETD Optical Gas MWIR Thermal Imaging Sensor Cooled 320x256
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Function||Gas Leak Detection||Cryo Cooler||RS058/RS058I/LS734|
|Detector Resolution||320x256||Pixel Size||30μm|
Gas MWIR Thermal Imaging Sensor,
10mK NETD Thermal Imaging Sensor,
320x256 Cooled Imaging Sensor
320x256 30μM MWIR Cooled Thermal Imaging Sensor For Visualizing Gas Leaks
C330M-G cooled infrared detector is specially developed for VOCs gas leak detection with the function of converting infrared radiation of target with 3.2~3.5μm wavelength into electrical signal. Its external mechanical interface, optical interface and electronic interface are commonly used and can be expanded. C330M-G can be widely used in atmospheric environment monitoring and gas leakage detection, pollutant discharge, chemical gas detection in petrochemical plants and refineries.
Optical Gas Imaging
• Long range non-contact detection
• High efficient, secure and wide range of gas leak detection
• High sensitive cooled infrared detector, quite efficient in application of low gas concentration and slow gas flow
• Effective leak detection includes Alkanes, Alkenes, Alcohols, Benzenes, Ketones and other gases
Designed for Requirements of Users
• Support 12V power supply for explosion-proof certification
• Various cryocoolers available for light weight, low power, long life and high reliability
• Customizable spectral range: 3μm~5μm MWIR (for more gas detection types: CO, CO2 etc.)
|Spectral Range||3.2μm±0.1μm～3.5μm±0.1μm (Cusomizable Range: 3μm~5μm)|
|Working Mode||Snapshot; ITR Integration Mode; Windows Mode; Anti-blooming|
|Number of Output||1 or 4; Up to 6.6MHz/per Output|
|Typical NETD||10mK (F1.5)|
|Effective Pixel Rate||≥99.5%|
|Cooler Type||Integral Rotary Stirling Cooler||Integral Rotary Stirling Cooler||Linear Rotary Stirling Cooler|
|Stable Power Consumption||≤7W||≤7W||≤10W|
|Max. Power Consumption||≤15W||≤15W||≤45W|
|Power Supply||24V DC||12V DC||24V DC|
|Size (mm)||142x58.5x71||142×58.5×71||Compressor Φ46×122
|Working Temperature||-45°C ~ +71°C|
The C330M-G gas leak detection cooled MWIR thermal imaging detector is used for customers who have strong development ability. By integrating this cooled thermal sensor, the invisible VOCs (volatile organic compounds) can be detected and visualized so that further damage can be avoided. These gases includes such as: Methane, Ethane, Propane, Butane, Pentane, Hexane, Heptane, Octane, Ethylene, Propylene, Isoprene, Methanol, Ethanol, Butanone, Benzene, Toluene, Xylene, Ethylbenzene etc.
1.What is infrared thermal imaging?
Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. According to the radiation difference between the object and the background environment and the radiation difference of each part of the object itself, the infrared thermal image can show the radiation fluctuation of each part of the scene, thus showing the characteristics of the scene.
2. What is the advantage of infrared thermal imaging?
---See through total darkness
---Identification under camouflage
---Long range detection
---Heat distribution detection
---Non-contact temperature measurement
---And so on
3. What is the applications of infrared thermal imaging?
Temperature measurement and all-weather imaging are two basic functions of infrared thermal imaging technology. Products developed based on these two technologies are widely used in electric power, security & monitoring, industrial manufacturing, scientific research, medical treatment and other traditional fields.
