320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks

I'm Online Chat Now

320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks

320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks
320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks

Large Image :  320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: GAS330
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Function: Gas Leak Detection Cryo Cooler: RS058
Detector Resolution: 320x256 Pixel Size: 30μm
NETD: ≤15mK Spectral Range: 3.2±0.1~3.5±0.1μm
High Light:

MWIR Cooled Optical Gas Imaging

,

320x256 Optical Gas Imaging Camera

GAS330 Cooled Infrared Module



320x256 / 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks



Product Description



Optical Gas Imaging (OGI) is an innovative thermal imaging technology that utilizes high sensitivity infrared cameras for detecting minute fugitive emissions of industrial gases.



GAS330 is a 320x256 / 30µm Cooled Optical Gas Imaging Camera. Its high sensitivity is suitable for detection scene with low gas concentration and slow gas flow rate. Inspectors can find the gas that pollutes the environment or is harmful to personnel assets, and timely avoid profitable gas loss.



Main Features



- Resolution: 320x256

- Pixel Pitch: 30µm

- NETD≤15mK, High Sensitivity

- Spectral Response: 3.2µm±0.1µm~3.5µm±0.1µm

- Wavelength Customizable Based on Different Requirements

- Integrate with DVP/CameraLink Interface Easily



Product Specifications



Model GAS330
IR Detector Performance
Resolution 320x256
Pixel Pitch 30μm
Cryocooler RS058
Spectral Range 3.2μm±0.1μm~3.5μm±0.1μm MW
Cooling Time (20°C) ≤8min
NETD (20°C) ≤15mK
Image Processing
Frame Rate 30Hz
Dimming Mode Linear/Histogram/Mixed
Digital Zoom ×1/×2/×4
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE
Electrical Specification
Standard External Interface J30JZ 25pin
Analog Video PAL
Digital Video 16bit RAW/YUV: 16bit DVP/Cameralink Output
External Sync Frame External Sync: RS422 Level
Communication RS422, 115200bps
Power Supply 20~28VDC
Stable Power Consumption 12W
Dimension (mm) 155×67×80
Weight ≤900g
Operation Temperature -40°C ~ +60°C
Vibration Magnitude Vibration: GJB Vehicle-mounted High Speed Transport
Shock: Half-sine Wave, 40g 11 ms, 3 Axis 6 Direction 3 Times Each
Optical Lens
Optional Lens Fixed Zoom: 23mm/F1.5; 55mm/F1.5



Industrial Applications



The GAS330 gas leak detection thermal imaging camera is used for visiualizing the invisible VOCs (volatile organic compounds) and detecting gas leakage such as: Methane, Ethane, Propane, Butane, Pentane, Hexane, Heptane, Octane, Ethylene, Propylene, Isoprene, Methanol, Ethanol, Butanone, Benzene, Toluene, Xylene, Ethylbenzene etc.



Exhibitions



320x256 30μm MWIR Cooled Optical Gas Imaging Camera for Visualizing Gas Leaks 0



FAQs



1. In which industries can the infrared detectors / thermal camera cores be used?



GST thermal camera modules are widely used in many industries such as:

- Thermography: Power Maintenance, Machine Vision, Building HVAC, Metallurgical Petrochemical, Predictive Maintenance, Epidemic Prevention
- Security & Monitoring: Safe City, Infrastructure Monitoring, Border Security, Maritime Cruising, Mining Safety
- Firefighting & Rescue: Forest Fire Prevention, Fire Prevention, Search & Rescue
- UAVs payload: Equipment Inspection, Enforcement & Rescue, Firefighting Application, Animal Observation
- Personal Vision: Outdoor Leisure, Animal Observation, Enforcement Patrol
- ADAS: Autonomous Driving, Advanced Driver Assistant System, Special Vehicles

- AIoT: Smart Home, Intelligent Hardware, Smart Care, Robots

- Others: Enhanced Flight Vision System, Gas Detection, Agriculture & Graziery, Scientific Research.
