55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection

I'm Online Chat Now

55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection

55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection
55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection

Large Image :  55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: GAS330
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Style: Cooled Infrared Module Resolution: 320x256 / 30μm
NETD: ≤15mK Spectral Range: 3.2±0.1~3.5±0.1μm
Size: 155x67x80mm Optional Lens: Fixed Zoom
High Light:

55mm Optical Gas Imaging Module

,

30Hz Optical Gas Imaging Module

,

VOCs Optical Gas Imaging Module

GAS330 by GST Infrared



320x256 / 30μm Cooled Infrared Camera Module with 55mm Lens for VOCs Gas Leak Detection



Product Description



Volatile Organic Compounds, or VOCs, are gases that are emitted into the air from products or processes. Once they leak, it will lead a fatal risk for both employees and local residents.



GAS330 is a cooled infrared thermal module specially designed for gas leakage detection. It integrates 320x256 / 30µm MCT cooled MWIR infrared detector and utilizes spectral wavelength filtering technology to visualize the invisible VOCs that cannot be seen by naked eyes.



It is a very fast, contact-less measurement tool which can be used in difficult-to-access places. By using this thermal camera, the safety of both the inspector and the inspected item will be significantly increased.



Main Features



- Resolution: 320x256

- Pixel Pitch: 30µm

- NETD≤15mK, High Sensitivity

- Spectral Response: 3.2µm±0.1µm~3.5µm±0.1µm

- Wavelength Customizable Based on Different Requirements

- Integrate with DVP/CameraLink Interface Easily



Product Specifications



Model GAS330
IR Detector Performance
Resolution 320x256
Pixel Pitch 30μm
Cryocooler RS058
Spectral Range 3.2μm±0.1μm~3.5μm±0.1μm MW
Cooling Time (20°C) ≤8min
NETD (20°C) ≤15mK
Image Processing
Frame Rate 30Hz
Dimming Mode Linear/Histogram/Mixed
Digital Zoom ×1/×2/×4
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE
Electrical Specification
Standard External Interface J30JZ 25pin
Analog Video PAL
Digital Video 16bit RAW/YUV: 16bit DVP/Cameralink Output
External Sync Frame External Sync: RS422 Level
Communication RS422, 115200bps
Power Supply 20~28VDC
Stable Power Consumption 12W
Dimension (mm) 155×67×80
Weight ≤900g
Operation Temperature -40°C ~ +60°C
Vibration Magnitude Vibration: GJB Vehicle-mounted High Speed Transport
Shock: Half-sine Wave, 40g 11 ms, 3 Axis 6 Direction 3 Times Each
Optical Lens
Optional Lens Fixed Zoom: 23mm/F1.5; 55mm/F1.5



Industrial Applications



The GAS330 gas leak detection thermal imaging camera is used for visiualizing the invisible VOCs (volatile organic compounds) and detecting gas leakage such as: Methane, Ethane, Propane, Butane, Pentane, Hexane, Heptane, Octane, Ethylene, Propylene, Isoprene, Methanol, Ethanol, Butanone, Benzene, Toluene, Xylene, Ethylbenzene etc.



Praises from Customers



55mm Lens Optical Gas Imaging Module For VOCs Gas Leak Detection 0



FAQs



1.What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. It converts invisible infrared radiation into visible infrared thermal image with temperature distribution of the target surface. Different objects and even different parts of the same object have different radiation ability and infrared reflection strength.



2.What can infrared imaging be used for?

-Night vision

-Search & rescue

-Non-destructive test

-Epidemic prevention

-Thermography

-Security & monitoring

-Firefighting



3.What is thermal imaging module?

A thermal imaging module usually consists of an infrared detector, infrared lens and hardware electronics with software and algorithm embedded. It is the minimum unit of a thermal imaging device.
