LWIR Uncooled Radiometric Thermal Imaging Module 640x512/12µm with Low Power Consumption 0.65W

  • LWIR Uncooled Radiometric Thermal Imaging Module 640x512/12µm with Low Power Consumption 0.65W
Place of Origin China
Brand Name SensorMicro
Certification ISO9001:2015; RoHS; Reach
Model Number COIN612RG2
Minimum Order Quantity 1 Piece
Price Negotiable
Payment Terms T/T
Product Details
Resolution 640x512 Power Consumption 0.65W
Spectral Range 8~14μm Pixel Pitch 12μm
NETD ≤25mK/F1.0/25℃ Frame Rate 25Hz/30Hz
Highlight

LWIR Uncooled Thermal Module 640x512

,

12um Detector Thermal Module

,

Detector LWIR Thermal Module
Leave a Message
Product Description
LWIR Uncooled Radiometric Thermal Imaging Module 640x512 12µm for Thermography
Product Overview

COIN612RG2 is a compact, low-power infrared temperature measurement camera core built with ApexCore 640*512/12μm infrared detector. Boasting high imaging sensitivity (NETD≤25mK) and precise temperature measurement of ±2°C/±2%, it supports dual temperature ranges of -20°C-150°C and 100°C-550°C with customizable expansion. Lightweight and miniaturized (25.4*25.4*15.7mm, 15±1g, ≤0.65W power consumption), it offers multiple image output methods and compatible optical lenses. Easy for secondary development and system integration, it perfectly fits industrial thermography, process control and intelligent manufacturing scenarios.

Main Features
  • Comprehensive Functionality, Cost-Effective Design: Developed using ApexCore wafer-level infrared detector with NETD≤25mK; combines widely used FPA with advanced image processing algorithms for enhanced image quality; temperature measurement accuracy up to ±2°C or ±2%, supporting ranges of -20°C to 150°C and 100℃ to 550°C, with customizable extensions
  • Compact and Lightweight, High Efficiency with Low Power: Dimensions: 25.4*25.4*15.7mm; Weight: 15±1g; Power consumption: ≤0.65W
  • Multiple Configurations, Rapid Integration: Optional optical lenses to meet diverse application requirements; supports USB2.0/DVP/LVDS/BT.656 image output interfaces; RAW/YUV/TMP image data output with serial port control
Product Specifications
Model COIN612RG2
IR Detectors Indicators Sensitive Material: VOx
Resolution: 640*512
Pixel Size: 12μm
Spectral Response: 8μm ~ 14μm
Typical NETD: ≤25mK/F1.0/25℃
Image Processing Digital Frame Rate: 25/30Hz
Start-up Time: 6s
Analog Video: PAL/NTSC
Digital Video: RAW/YUV422/TMP
Image Algorithm: Non-uniformity Correction (NUC), 3D Noise Reduction (3DNR), 2D Noise Suppression (DNS), Dynamic Range Compression (DRC), Edge Enhancement (EE)
Image Display: 10 Types (White Hot/Lava/Iron Red/Hot Iron/Medical/Arctic/Rainbow 1/Rainbow 2/Tint/Black Hot)
PC Software ICC Software: Module Control & Video Display
Electrical Standard External Interface: 50pin: DF40C-50DP-0.4V(51), (HRS,Male)
USB Expansion Board: USB3.0/USB2.0/VPC/USB2.0&VPC
Communication Interface: TTL-232/USB2.0
Digital Video Interface: DVP8/DVP16/USB2.0/BT.656/LVDS
Supply Voltage: 4.5~5.5V
Typical Power Consumption: 0.65W
Temperature Measurement Operating Temperature: -10℃~+50℃
Temperature Measurement Range: -20℃~150℃, 100℃~550℃; Support Customization and Expansion
Temperature Measurement Accuracy: ±2°C or ±2% (whichever is greater)
Partial Temperature Measurement: Support output maximum, minimum and average value of temperature measurement areas
SDK: Android/Windows/Linux; Achieve Video Stream Analysis and Conversion from Gray to Temperature
Mechanical Bare Core Size(mm): 25.4*25.4*15.7mm
Bare Core Weight(g): 15±1g
Environmental Adaptability Operating Temperature: -40℃~+70℃
Storage Temperature: -45℃~+85℃
Humidity: 5%~95%, non-condensing
Vibration: 5.35grms, Random Vibration, 3-axis
Impact: Half Sine Wave, 40g/11ms, Impact Direction 3 Axis, 6 Direction
Certification: ROHS2.0/REACH
Optical Lens Optical Lens: Fixed Focus Athermal: 4.8mm/7mm/9.1mm/13mm/19mm/25m/35mm
Protection Level: IP67(Front Lens)
Industrial Applications

The COIN612RG2 thermal imaging module is applied to the field of Thermography, Industrial Vision, Firefighting and Rescue, Security Surveillance, Outdoor Observation, Machine Vision, Consumer Electronics etc.

Our Advantages
  • A wide range of product formats including infrared detectors, camera cores, and modules to meet various integration requirements
  • Rich Product Variety: Multiple array resolutions, pixel sizes, wavebands, and lens options combinations provide greater flexibility for diverse applications
  • Outstanding Performance: Clear imaging, compact size, low power consumption, high sensitivity, and strong reliability—designed to perform under a wide range of environmental challenges
  • Easy Integration: Multiple interface options make integration straightforward and enable rapid development across multiple application fields
Frequently Asked Questions
1. What is the difference between infrared and thermal imaging?
Infrared refers to the range of electromagnetic radiation beyond visible light, while thermal imaging is a technology that utilizes infrared radiation to capture the temperature variations of objects and create visual representations of their heat patterns. In simple terms, thermal imaging is one application of infrared technology.
2. Can infrared detect hidden objects?
Infrared technology can sometimes detect hidden objects by detecting differences in temperature between the object and its surroundings. For example, infrared cameras can be used to locate hidden heat sources, such as living organisms or overheating electrical components, that may not be visible to the human eye.
3. How accurate is infrared temperature measurement?
Infrared temperature measurement can provide reasonably accurate results when used correctly. However, accuracy can be affected by factors such as distance, emissivity (surface properties of the object being measured), environmental conditions, and the quality of the infrared thermometer or camera being used.
