RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM

I'm Online Chat Now

RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM

RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM
RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM
video play

Large Image :  RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: GAVIN1212
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
High Definition: 1280x1024 Pixel Pitch: 12μm
Frame Rate: 50Hz/100Hz NETD: ≤20mK
Size: 165x86x107mm Spectral Range: 3.7~4.8μm MW
High Light:

RS422 Cooled Ir Detector

,

Cooled Ir Detector 12uM

,

99.5% Pixel Rate Cooled Camera Modules

Megapixel GAVIN1212 Cooled Camera Core



Long Range Detection 1280x1024 / 12μm MWIR MCT Cooled Camera Module with 37.5~750mm Zoom Lens



Product Description



GAVIN1212 high resolution thermal camera module integrates large array 1280x1024/12μm cooled MWIR detector. Various image processing algorithms are embedded in the GAVIN1212 electronics to output clear infrared images in the total darkness or bad weather conditions. It can detect and recognize risks and threats at long distance while present more target details at short distance.



With large array 1280x1024 resolution it can realize wider field of view and provide more image details. The reduced 12µm pixel size offer better spatial resolution and match shorter optical lens focus to achieve the same range mission. It is ideal choice for the EO-IR systems integrator to design their payload for air-borne or ship-borne applications.



Main Features



Mega Pixel Images
• 1280×1024 high definition for wider FOV and longer distance
• 12μm pixel size for better spatial resolution



Sharp Clear Quality
• Good uniformity, effective pixel rate>99.5%
• High sensitivity, NETD≤20mK



Fast Integration
• Support Cameralink interface, RAW/YUV image data output
• Various continuous zoom optical configurations are optional



Product Specifications



Model GAVIN1212
IR Detector Performance
Resolution 1280x1024
Pixel Pitch 12μm
Cryocooler RS058F
Spectral Range 3.7μm~4.8μm MW
Cooling Time(20°C) ≤8min
NETD (20°C) ≤20mK
Image Processing
Frame Rate 50Hz/100Hz
Dimming Mode Linear/Histogram/Mixed
Digital Zoom ×1/×2/×4
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE
Electrical Specification
Standard External Interface J30JZ 25pin; HDMI Special Output Interface
Analog Video /
Digital Video HDMI Output: YUV
Cameralink Output: 16bit RAW/YUV
External Sync

Frame External Sync: RS422



Communication RS422, 115200bps
Power Supply 24V±1V
Stable Power Consumption 16W
Dimension (mm) 165x86x107
Weight ≤1600g
Operation Temperature -40°C ~ +60°C
Vibration Magnitude Vibration: GJB Vehicle-mounted High Speed Transport
Shock: Half-sine Wave, 40g 11 ms, 3 Axis 6 Direction 3 Times Each
Optical Lens
Optional Lens Continuous Zoom: 37.5~750mm/F4
Fixed Zoom: 19mm/F2; 40mm/F2; 240mm/F2



Industrial Applications



The GAVIN1212 thermal infrared camera module is widely used many areas such as Remote Monitoring System, Flight Vision Enhancement System, Multi-sensor Payload etc.



RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM 0



IR Detection Solutions



RS422 99.5% Pixel Rate Cooled Ir Detector Module Core 1280x1024 12μM 1



FAQs



1. What is MCT/HgCdTe detector?

MCT, also called HgCdTe, refers to Mercury-Cadmium-Tellurid which is a chemical compound of cadmium telluride (CdTe) and mercury telluride (HgTe) and a common material in photodetectors. MCT/ HgCdTe detector is a photoconductive detector that operates at a cryogenic environment and can detect infrared radiation. It is more sensitive than the thermal sensors.



2. What is T2SL detector?

T2SL refers to Type-II Superlattice, which is an artificial material with alternating growth periodic heterojunction at nanometer size. It has high uniformity and superior optical property, such as large electron effective mass,large absorption coefficient and high quantum efficiency. Compared with MCT infrared detector, the T2SL infrared detector has good material uniformity, low cost, and similar performance to MCT infrared detector in medium and long wave band, but has great advantages in very long wave band.
