LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement

I'm Online Chat Now

LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement

LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement
LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement

Large Image :  LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: LC260
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Resolution: 256x192 Pixel Pitch: 12μm
Temperature Range: 20℃~50℃ Power Consumption: ≤700mW
High Light:

LC260 Thermal Camera Core

,

256x192 Resolution Thermal Camera Core

,

Body Temperature Thermal Camera Core 12uM

LC260 Thermal Camera Core



LC260 Tiny Size 256x192 / 12μm Thermal Camera Core for Human Body Temperature Measurement



Product Description



Miniature size LC260 infrared module integrates the wafer level packaging 256x192 / 12μm uncooled infrared detector and is specially designed for body temperature measurement.



The LC260 infrared module has an temperature range from 20℃~50℃ and an accurate temperature range from 28℃~42℃. Its measuring distance could reach 0.5~2.5 meters. With SDK and USB interface, the LC260 uncooled thermal module can be easy to be integrated for secondary development.



Global Sensor Technology is a supplier of thermal infrared detectors and infrared camera module. After years of industrial application experience, we are capable to provide professional, efficient and convenient solutions for customers in all industries with its core technology of independent R&D infrared detector.



Main Features



- IR resolution 256×192
- IR module for body temperature measurement
- Enable measuring real-time body temperature for multiple users
- Far distance accurate temperature measurement, 0.5-2.5 meters
- Original installing hole, easy for customer to integrate
- With SDK and USB interface, easy for integrated development



Product Specifications



Version LC260
IR Resolution 256×192@12μm
FOV 56°×42°
Focal Length 3.2mm #F1.1
Interface USB Type-C USB 2.0 protocol
Power Consumption ≤700mW
Accuracy ±0.5℃ (Environment Temperature +10℃~+35℃)
Temperature Range 20℃~50℃ | Accurate Temperature Range 28℃~42℃
Measuring Distance 0.5~2.5 Meters
SDK Android / Linux x86&x64 / Windows x86&x64
Authentication RoHS



Industrial Applications



This product is positioning the field of security and protection. The target customer group is smart face recognition large-screen equipment manufacturers and OEM/ODM manufacturers. The terminal products are used for multi-user fast body temperature measurement in places like factories, office buildings, community entrances, supermarkets, government affairs centers, hospitals and other places with large flow of people or easy to gather people.



LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement 0



Our IR Detector Solutions



LC260 256x192 12μM Thermal Camera Core For Human Body Temperature Measurement 1



FAQs



1. What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. According to the radiation difference between the object and the background environment and the radiation difference of each part of the object itself, the infrared thermal image can show the radiation fluctuation of each part of the scene, thus showing the characteristics of the scene.



2. What is the advantage of infrared thermal imaging?

---See through total darkness;

---Identification under camouflage;

---Long range detection;

---Heat distribution detection;

---Non-contact temperature measurement;

---Occupation awareness



3. What is the applications of infrared thermal imaging?

Temperature measurement and all-weather imaging are two basic functions of infrared thermal imaging technology. Products developed based on these two technologies are widely used in electric power, security & monitoring, industrial manufacturing, scientific research, medical treatment and other traditional fields.
