Body Temperature Screening Thermal Module Uncooled 384x288 17μM

Place of Origin Wuhan, Hubei Province, China
Brand Name GST
Certification ISO9001:2015; RoHS; Reach
Model Number iHA417W
Minimum Order Quantity 1 Piece
Price Negotiable
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Resolution 384x288 Power Consumption 0.85W
Spectral Range 8~14μm Pixel Pitch 17μm
Typical NETD <50mk Frame Rate 25Hz
High Light

Body Temperature Screening Thermal Module 17uM

,

Thermal Module Uncooled 384x288

,

5m Fever Detection Thermal Camera

Leave a Message
Product Description
iHA417W Medical Diagnosis Thermal Module


Thermal Module For Body Temperature Screening Uncooled 384x288/17μM



Product Description



iHA417W thermal module is specially developed for medical diagnosis. It is integrated with self-developed wafer level packaging 384×288/17μm infrared detector, 9.1mm lens, 30pin standard interface (Optional Type-C expansion board) and a dedicated SDK for medical temperature measurement.



There are two modes of temperature measurement distance: 5 meters and 0.5 meters, which can be used in various scenarios. The iHA417 medical diagnosis thermal module has a better temperature measurement consistency and superior temperature measurement accuracy of ±0.5°C. No need for built-in black body ensures a compact design and easier temperature measurement.



The iHA417W thermal camera module can be quickly integrated into various medical thermal imaging devices, and it is expected to be widely used in the fields of Disease Screening, Traditional Chinese Medicine Physiotherapy, Health Check-up, Rehabilitation etc. at present and in the future.

Main Features


- Small Size: 25.4mm×25.4mm×30.3mm (with lens)
- Typical NETD<50mk
- Detect Distance: 0.5m/5m
- Light Weight as Low as 32.2g
- Superior Temperature Measurement Accuracy: ±0.5℃



Product Specifications



Model iHA417W
IR Detector Performance
Resolution 384×288
Pixel Size 17μm
Spectral Range 8~14μm
Typical NETD <50mk
Image Processing
Frame Rate 25Hz
Start-up Time 5s
Digital Video RAW/YUV
Image Display Black Hot/White Hot/Pseudo Color
Image Algorithm NUC/3DNR/DNS/DRC/EE/SFFC
Electrical Specification
Standard External Interface Type-C
Communication Mode USB
Supply Voltage 5±0.5V
Typical Power Consumption 0.85W
Temperature Measurement
Operating Temperature Range -10°C ~ +50°C
Temperature Measurement Range 15℃ ~ 50℃
Temperature Measurement Accuracy ≤±0.5℃ (No wind indoor, target temperature range 32℃~42℃)
Measuring Distance Two Modes: 0.5m or 5m
SDK Support Windows/Android/Linux SDK, Achieve Full Screen Thermography
Physical Characteristics
Size (mm) ≤25.4×25.4×30.3 (With 9.1mm Lens)
Weight 32.2±3g (With 9.1mm Lens)
Environmental Adaptability
Operating Temperature -40°C ~ +70°C
Storage Temperature -45°C ~ +85°C
Humidity 5%~95%, non-condensing
Vibration Random Vibration 5.35grms, 3 Axis
Shock Half-sine Wave, 40g/11ms, 3 Axis 6 Direction
Optics
Optional Lens Fixed Focus Athermal: 9.1mm
Certificate
Standard ROHS/REACH



Detect Distance

Body Temperature Screening Thermal Module Uncooled 384x288 17μM 0

Industrial Applications


The iHA417 thermal module is expected to be widely used in the fields of Disease Screening, Traditional Chinese Medicine Physiotherapy, Health Check-up, Rehabilitation etc. at present and in the future.
Body Temperature Screening Thermal Module Uncooled 384x288 17μM 1

Our Advantages




Body Temperature Screening Thermal Module Uncooled 384x288 17μM 2


FAQs



1. What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. According to the radiation difference between the object and the background environment and the radiation difference of each part of the object itself, the infrared thermal image can show the radiation fluctuation of each part of the scene, thus showing the characteristics of the scene.



2. What is the advantage of infrared thermal imaging?

---See through total darkness

---Identification under camouflage

---Long range detection

---Heat distribution detection

---Non-contact temperature measurement

---Occupation awareness

---And so on



3.What are the key considerations on an infrared detector / thermal module for your application?

---The detector resolution

---The pixel size

---The NETD

---The image quality

---The lens options

---The power consumption

---The size and weight

---The mechanical & electrical interface

---The budget
