Home ProductsCooled Camera Modules

100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM

I'm Online Chat Now

100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM

100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM
100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM

Large Image :  100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: GAVIN615A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Type: Cooled Camera Module Technology: MCT/HgCdTe
Resolution: 640x512/15μm High Sensitivity: NETD≤15mK
Size: 155x67x80mm Mid Wavelength: 3.7~4.8μm
High Light:

MWIR Thermal Imaging Module 15uM

,

100Hz Thermal Imaging Module

,

HgCdTe Cooled Camera Modules

High Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM

GAVIN615A Cooled Thermal Camera Core



High Frame Rate Cooled HgCdTe 640x512 / 15μm MWIR Thermal Imaging Module with RS058 Cryo Cooler



Product Description



GAVIN615A is a cooled mid wave thermal imaging module developed by Global Sensor Technology (GST). It consists of a 640x512@15µm HgCdTe MWIR IR detector with RS058 cryocooler, hardware electronics and various image processing algorithms are also embedded already to present sharp and clear thermal images.



When integrated with F2 640x512 / 15µm HgCdTe MWIR IR detector, the frame rate of GAVIN615A can be configured up to 100Hz, which is very suitable for applications that require observation on fast moving objects.



Until now, we have provided our customers with various mature and stable infrared thermal imaging solutions. It is easy for OEM customers to carry out fast acceptance test on GST thermal modules, start rapid secondary development and greatly reduce the cost of their development.



Main Features



- Meet the Needs of Long Range Detection

- High Sensitivity, NETD≤15mK

- High Frame Rate

- High Quality Thermal Imaging

- Easy Integration into the System



Product Specifications



Model GAVIN615A
IR Detector Performance
Resolution 640x512
Pixel Pitch 15μm
Cryocooler RS058
Spectral Range 3.7μm~4.8μm MW
Cooling Time (20°C) ≤7min
NETD (20°C) ≤15mK
Image Processing
Frame Rate 50Hz/100Hz
Dimming Mode Linear/Histogram/Mixed
Digital Zoom ×1/×2/×4
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE
Electrical Specification
Standard External Interface J30JZ 25pin
Analog Video PAL
Digital Video 16bit RAW/YUV: 16bit DVP/Cameralink Output
External Sync Frame External Sync: RS422 Level
Communication RS422, 115200bps
Power Supply 20~28VDC
Stable Power Consumption 12W
Dimension (mm) 155×67×80
Weight ≤900g
Operation Temperature -40°C ~ +60°C
Vibration Magnitude Vibration: GJB Vehicle-mounted High Speed Transport
Shock: Half-sine Wave, 40g 11 ms, 3 Axis 6 Direction 3 Times Each
Optical Lens
Optional Lens Continuous Zoom
30~240mm/F4
15~300mm/F4
21~420mm/F4
35~690mm/F4



Industrial Applications



The GAVIN615A thermal infrared camera module is widely used many areas such as Remote Monitoring System, Flight Vision Enhancement System, Multi-sensor Payload etc.



100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM 0



Exhibiitons



100Hz Frame Rate MWIR Thermal Imaging Module Cooled HgCdTe 640x512 15μM 1



FAQs



1. What is infrared thermal imaging?

Infrared thermal imaging is a method of using infrared radiation and thermal energy to gather information about objects, in order to formulate images of them, or get temperature information of the objects, even in low visibility environments.



2.In which industries are focal plane array infrared detectors used in?

Infrared focal plane detector is the core component of thermal imaging system, and is the key to detect, identify and analyze infrared information of objects. It has a wide range of applications in traffic, inspection, security monitoring, meteorology, medicine and other industries.



3. What are the characteristics of cooled & uncooled infrared focal plane detector?

Infrared focal plane detectors can be divided into cooled infrared focal plane detector and uncooled infrared focal plane detector. Cooled infrared detector works at a low temperature vacuum environment with high sensitivity and can distinguish more subtle temperature differences, while uncooled infrared focal plane detector does not need a cryogenic environment and can work at room temperature.



4. How to choose a suitable infrared thermal camera lens?

- Standard lens can meet normal targets with appropriate distance

- For the telephoto lens, it’s suitable for targets that is relatively small and needs to be viewed from a long distance

- To see more detail of objects at close distance, wide angle lens is better.

- Macro lens is for seeing very tinny target with close distance, such as chip circuit.
