Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm

I'm Online Chat Now

Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm

Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm
Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm

Large Image :  Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: iHA417
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Resolution: 400x300/17μm NETD: <50mK
Spectral Range: 8~14μm Size: 44.5x42.5x58.9mm
High Light:

Uncooled Thermal Camera For Fever Detection

,

30mk Thermal Camera For Fever Detection

iHA417 Thermal Module



Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm Infrared Detector



Product Description



iHA417 uncooled infrared thermal camera is specially developed for infrared (IR) fever sensing system in order to measure human body temperature anytime and anywhere. It consists of 400×300 / 17μm infrared detector, 7mm infrared optical lens and a specialized SDK for human body temperature measurement.



Data captured by iHA417 can be transferred to the back-end integration platform via 50-pin or USB3.0 interface to achieve the display of full-screen temperature data and infrared thermal image and many other functions. With such infrared thermal imaging module, customers could develop and integrate their own IR fever sensing system quickly and efficiently.



The iHA417 thermal camera is specially developed for elevated skin temperature screening. It is easy to be integrated into infrared thermographic system which has been used for fighting against COVID-19. and fast to detect elevated body temperature in places that have large volume of people, such as airports, subways, train stations, schools, shopping centers, etc.



Main Features


- NETD<30mk, High Sensitivity
- Easy to Integrate
- Non-contact Design
- Field of View: 37.2°×28.3°
- Temperature Difference: ±0.5℃
- Temperature Measurement Distance: Optimal 5 Meters



Product Specifications



Model iHA417
IR Detector Performance
Resolution 400x300
Pixel Pitch 17μm
Spectral Range 8~14μm
NETD <30mK
Image Processing
Frame Rate 25Hz
Start-up Time <10s
Extension Component USB Video
Dimming Mode Linear/Histogram/Mixed
Image Display Black Hot/White Hot/Pseudo Color
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE/DNR
Electrical Specification
Standard External Interface TYPE-C
Communication Mode USB
Supply Voltage 5±0.5V
Typical Power Consumption <1.5W
Temperature Measurement
Operating Temperature Range 16°C ~ 32°C
Temperature Range 20°C ~ 50°C
Temperature Accuracy ≤±0.5°C (No Wind Indoors, 32°C~42°C Target)
SDK ARM/Windows SDK, Full Screen Thermography
Physical Characteristics
Dimension (mm) 44.5x42.5x58.9 (PLUG417S+7mm Lens)
Weight PLUG417S+7mm Lens≤135g
Environmental Adaptation
Operation Temperature -10°C ~ +50°C
Storage Temperature -45°C ~ +85°C
Humidity 5%~95%, Non-condensing
Vibration Random Vibration 5.35grms, 3 Axis
Shock Half-sine Wave, 40g/11ms, 3 Axis 6 Direction
Optics
Optional Lens Fixed Focus Athermal: 7mm
Certification
Certification Standards ROHS/REACH



Industrial Applications



The iHA417 thermal camera is widely used in human body temperature measurement and elevated body temperature screening.



Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm 0



Global Sensor Technology Team



Uncooled Thermal Camera for Fever Detection with LWIR 400x300 / 17μm 1



FAQs



1. What is infrared thermal imaging?

Infrared thermal imaging is a kind of method which utilizes infrared radiation and thermal energy to gather information about objects. According to the radiation difference between the object and the background environment and the radiation difference of each part of the object itself, the infrared thermal image can show the radiation fluctuation of each part of the scene, thus showing the characteristics of the scene.



2. What is the advantage of infrared thermal imaging?

---See through total darkness;

---Identification under camouflage;

---Long range detection;

---Heat distribution detection;

---Non-contact temperature measurement;

---Occupation awareness



3. What is the applications of infrared thermal imaging?

Temperature measurement and all-weather imaging are two basic functions of infrared thermal imaging technology. Products developed based on these two technologies are widely used in electric power, security & monitoring, industrial manufacturing, scientific research, medical treatment and other traditional fields.
