LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis

I'm Online Chat Now

LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis

LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis
LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis

Large Image :  LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis

Product Details:
Place of Origin: Wuhan, Hubei Province, China
Brand Name: GST
Certification: ISO9001:2015; RoHS; Reach
Model Number: iHA417
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Payment Terms: L/C, T/T
Detailed Product Description
Resolution: 400x300/17μm NETD: <50mK
Spectral Range: 8~14μm Size: 44.5x42.5x58.9mm
High Light:

LWIR Fever Screening Thermal Camera

,

400x300 Fever Screening Thermal Camera

,

25Hz Thermal Camera Module

iHA417 Thermal Camera Module



400x300 / 17μm Uncooled VOx LWIR Fever Screening Thermal Camera for Medical Diagnosis



Product Description



iHA417 fever screening thermal camera consists of 400×300 / 17μm infrared detector, 7mm infrared optical lens and a specialized SDK for human body temperature measurement. Its accuracy level is within ±0.5°C (±1°F) that can be used to screen human body elevated temperature.

Compared with the normal thermometer in the market, the thermal camera with microbolometer sensors has accuracies of +/- 0.5 °C or better.



This screening thermal camera is very useful when every person needs to be tested for a fever before entering areas with a large number of people. Places like supermarket, hospital, subway, supermarket, station, school and so on can be integrated with this camera.



Main Features


- NETD<30mk, High Sensitivity
- Easy to Integrate
- Non-contact Design
- Field of View: 37.2°×28.3°
- Temperature Difference: ±0.5℃
- Temperature Measurement Distance: Optimal 5 Meters



Product Specifications



Model iHA417
IR Detector Performance
Resolution 400x300
Pixel Pitch 17μm
Spectral Range 8~14μm
NETD <30mK
Image Processing
Frame Rate 25Hz
Start-up Time <10s
Extension Component USB Video
Dimming Mode Linear/Histogram/Mixed
Image Display Black Hot/White Hot/Pseudo Color
Image Direction Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC/AGC/IDE/DNR
Electrical Specification
Standard External Interface TYPE-C
Communication Mode USB
Supply Voltage 5±0.5V
Typical Power Consumption <1.5W
Temperature Measurement
Operating Temperature Range 16°C ~ 32°C
Temperature Range 20°C ~ 50°C
Temperature Accuracy ≤±0.5°C (No Wind Indoors, 32°C~42°C Target)
SDK ARM/Windows SDK, Full Screen Thermography
Physical Characteristics
Dimension (mm) 44.5x42.5x58.9 (PLUG417S+7mm Lens)
Weight PLUG417S+7mm Lens≤135g
Environmental Adaptation
Operation Temperature -10°C ~ +50°C
Storage Temperature -45°C ~ +85°C
Humidity 5%~95%, Non-condensing
Vibration Random Vibration 5.35grms, 3 Axis
Shock Half-sine Wave, 40g/11ms, 3 Axis 6 Direction
Optics
Optional Lens Fixed Focus Athermal: 7mm
Certification
Certification Standards ROHS/REACH



Industrial Applications



The iHA417 thermal camera core is widely used in human body temperature measurement and elevated body temperature screening.



LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis 0



IR Detectors by GST Infrared



LWIR Fever Screening Thermal Camera Module 400x300 17μm for Medical Diagnosis 1



FAQs



1. What is infrared thermography?

Thermography is a new and effective technology of non-invasive diagnostic method based on object surface temperature detection. The infrared (IR) radiation emitted from an object is recorded and visualized in the form of a temperature distribution map.



2. What can the infrared thermography be used for?

The infrared thermal image can be used to perform home inspections, determine structural defects, electrical faults, mechanical faults, physiological changes in people & animals and much more.



3. What are the advantages of infrared thermography?

For the non-destructive test, it is simple to test and quick to response without damage, which results in saving costs, increasing work efficiency, reducing manpower and equipment depreciation.

For the medical thermography, it is very efficient to find the hidden problems in human body, 100% safe without radiation and pain, which is an ideal tool for early health screening.
