High Sensitivity Cooled Infrared Detectors With RS058 Cryo Cooler

Place of Origin Wuhan, Hubei Province, China
Brand Name GST
Certification ISO9001:2015; RoHS; Reach
Model Number C330S LWIR
Minimum Order Quantity 1 Piece
Price Negotiable
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Resolution 320x256 / 30μm NETD ≤25mK
Long Wavelength 7.7~9.5 (LW) Cooling Time <5min30s
Size 142x58.5x71mm Weight ≤600g
High Light

600g Cooled Infrared Detectors

,

RS058 Cooled Infrared Detectors

Leave a Message
Product Description
C330S LWIR Cooled Infrared Detector



High Sensitivity 320x256 / 30µm LWIR Cooled Infrared Detector with RS058 Cryo Cooler



Product Description



C330S LWIR cooled infrared detector features in the format of 320x256 resolution at 30μm pixel pitch. It is based on the world's leading Type II Supperlattice technology which enables mass production capability and thus ultimately it will benefit the users with more affordable price but never compromise in performance. The industrial standard size and interface enable customers to switch to and benefit from the most advanced T2SL technology without further R&D investment.



Without fear of interference, C330S LWIR integrated dewar cooler assembly is suitable for target detection in complex background, such as ships on the sea in the scene of light reflection on the water surface, aircraft in the background of clouds in the sky, etc.



Main Features



- Resolution: 320x256

- Pixel Pitch: 30µm

- High Sensitivity

- Good Imaging Effect

- Low Noise

- Stable Performance

- Excellent Non-uniformity



Product Specifications



Model C330S LWIR
Material T2SL
Resolution 320x256
Pixel Pitch 30μm
Spectral Range 7.7μm~9.5μm LW
Working Mode Snapshot; ITR Integration Mode; Windows Mode; Anti-blooming
Charge Capacity 36Me-/12Me-
Dynamic Range ≥80dB
Output Channel 1 or 4; Up to 6.6 Mpixel/s per Output
NETD ≤25mK (F2)
Effective Pixel Rate ≥99.5%
Response Non-uniformity ≤8%
Cooler Type RS058
Steady Power Consumption <8W
Max Power Consumption <17W
Power Supply 24V DC
Cooling Time <5min30s
Weight ≤600g
Dimension (mm) 142x58.5x71
Working Temperature -45°C ~ +71°C



Industrial Applications


The C330S LWIR cooled IR detector is widely used many areas such as Remote Monitoring System, Flight Vision Enhancement System, Multi-sensor Payload etc.

High Sensitivity Cooled Infrared Detectors With RS058 Cryo Cooler 0


Advantages


High Sensitivity Cooled Infrared Detectors With RS058 Cryo Cooler 1


FAQs



1. In which industries can the infrared detectors/thermal camera cores be used?



GST thermal camera modules are widely used in many industries such as:



- Thermography: Power Maintenance, Machine Vision, Building HVAC, Metallurgical Petrochemical, Predictive Maintenance, Epidemic Prevention

- Security & Monitoring: Safe City, Infrastructure Monitoring, Border Security, Maritime Cruising, Mining Safety

- Firefighting & Rescue: Forest Fire Prevention, Fire Prevention, Search & Rescue

- UAVs payload: Equipment Inspection, Enforcement & Rescue, Firefighting Application, Animal Observation

- Personal Vision: Outdoor Leisure, Animal Observation, Enforcement Patrol

- ADAS: Autonomous Driving, Advanced Driver Assistant System, Special Vehicles

- AIoT: Smart Home, Intelligent Hardware, Smart Care, Robots

- Others: Enhanced Flight Vision System, Gas Detection, Agriculture & Graziery, Scientific Research.
